L4 Ultra Handheld Laser Marking Machine

Meenjet L4 Ultra Handheld Laser Marking Machine

· 10W semiconductor laser for sharp, permanent marks.

· Ultra-light 1.1 kg body + 0.55 kg battery.

· 5" HD touchscreen with smart Linux OS.

· 50×50 mm marking area for precise marking.

· Works on metal, leather, wood, etc.

· Removable 86.58 Wh battery for portable use.

Overview
The Meenjet L4 Ultra is a compact, powerful and versatile handheld laser marking machine. Equipped with a 10W semiconductor laser (450 nm), it delivers sharp, permanent marks on wood, coated metal, stainless steel, marble, leather, dark opaque acrylic, felt, fabric, rubber, cardstock, ceramic and photo paper. Featuring a 5-inch HD touchscreen with an embedded Linux system, it ensures intuitive control. Powered by a DC 12.6V removable battery (86.58 Wh), it supports precise 50×50 mm marking anytime, anywhere.
Marking Capabilities
· Dynamic Data: Real-time text, serial numbers, QR codes, barcodes, images, date/time and variable database.
· Traceability: High-density 1D/2D codes for product tracking.
· Branding: Crisp logos and custom graphics on a wide range of materials.

Warranty
· 1-year warranty.
· Lifetime technical support.
· Please contact us for any application questions.

Parameter	Specification
Laser Source	Semiconductor
Wavelength	450nm
Laser Power	≥ 10W
Laser Tube Working Life	5000 working hours
User Interface	5" HD touch screen
Operating System	Embedded Linux
Power Supply	DC 12.6V removable battery (86.58Wh)
Marking Area	50mm × 50mm
Preview Mode	Blue light aiming box + Print image preview
Focus Distance Guidance	Fixed focus distance (modular design)
File Formats	JPG, PNG, BMP, etc
Cooling System	Air cooling
Working Environment	10°C to 40°C, max humidity 95%, non-condensing
Printable Content	Text, serial numbers, QR codes, barcodes, images, date/time, variable database
Supported Materials	Wood, coated metal, stainless steel, marble, leather, dark opaque acrylic, felt, fabric, rubber, cardstock, ceramic, photo paper
