Industrial & High-Speed
Maintenance-Free: All-electric design with lower operational costs.
High-Speed Output: Pro-grade performance at 220 packs/min.
HD 300DPI Print: Sharp, high-res barcodes, QRs, and logos.
Universal Integration: Supports both Intermittent and Continuous lines.
Intuitive UI: 7-inch industrial touchscreen with multi-language support.
Material Compatibility
The MOT Thermal Transfer Overprinter(TTO) series is engineered to work with a broad selection of ribbons, ensuring high-quality adhesion on various substrates, including:
Flexible Films: PET, PE, CPP, and laminated films.
High-Resistance Labels: Substrates requiring high-temperature resistance or anti-migration properties.
Packaging Pouches: Stand-up pouches, pillow bags, and sachet materials.
Industries & Applications
Our TTO solutions are widely adopted across multiple industries for reliable, fail-safe performance:
Food & Beverage: Ideal for printing expiry dates and batch numbers on snack bags and frozen food packaging.
Pharmaceuticals: Precise coding on medical pouches and blister packs.
Chemicals & Cosmetics: Durable printing for daily chemical products and beauty packaging.
| Type | MOT32 | MOT53 |
| Resolution | 300DPI | 300DPI |
| Inter. Print Area | 32 x 55mm | 53 x 55mm |
| Cont. Print Area | 32 x120mm | 53 x120mm |
| Ribbon Length | 600m | 600m |
| Standard Ribbon width | 33mm | 55mm |
| Print Mode | Intermittent and Continuous Integration | |
| Left and right | Optional | |
| Cont. Print Speed | 50~600mm/s | |
| Max prints | 220packs/min | |
| Print contents | Date, post date, time, counter, shift, Bar code, QR code, LOGO, text | |
| Input | Print signal, Encoder signal (NPN, PNP) | |
| Output | Fault relay output | |
| Dimensions (mm) | 164 x 158 x 166 | 164 x 158 x 187 |
| Printer weight | 6.8kg | 7.0kg |
| Power supply | 110/220V AC, 50/60 Hz, 120W | |
| Operation Environmental | Temperature: 5 - 40 ℃ Humidity: 10% - 90%, non-condensing | |
| Operating interface | 7-inch touch screen, multi-languages available | |
| Air Supply | No need air Supply | |
Meenjet Thermal Transfer Overprinter MOT Series Specification.pdf
Printing Performance & Effects
The MOC series ensures precise, high-resolution visuals through cutting-edge synchronous printing:
Dynamic Content: Real-time date, post date, time, counter, and shift info.
Traceability: High-density Bar codes and QR codes.
Branding: Crisp company LOGOs and custom text.
